OPEN CNC (Basic Operation Package 1 for Windows95/NT) Operators manual Page 300

Operators manual
7. SYSTEM B-62994EN/02
-282-
l Operation soft keys
Press the operation selection key .
The operation soft keys appear.
For details of each function, see the description below.
Operation
l Page
• Pressing the [PageUp] key displays the previous page of the history
information.
• Pressing the [PageDown] key displays the next page of the history
information.
• Pressing the soft key displays the first (oldest) page of the
history information.
• Pressing the soft key displays the last (newest) page of the
history information.
7.18.1 Clearing the operation history information
This section describes how to clear the operation history information.
Procedure
1. If the [Operation History] screen is currently not displayed, display the
[Operation History] screen as explained in Section 7.18, "Displaying
the Operation History."
