1. SETUP B-62994EN/02

-4-

1.2 Installing Basic Operation Package 1

This section describes how to install Basic Operation Package 1.

Procedure

ll WIN32 version

•• Installing Basic Operation Package 1

1. Insert the disk (A02B-0207-K750#ZZ07-2) into the floppy disk

drive.

2. Click the [Start] button.

3. Select [Run].

4. Enter <drive-name>:SETUP, then click the <OK> button. (<drive-

name> is the name of the 3.5-inch floppy disk drive.)

5. Perform installation according to the displayed messages.

6. Upon the completion of installation, restart the personal computer.

The setup program of Basic Operation Package 1 installs the English

version by default. To display non-English messages (Japanese,

German, French, Italian, or Spanish), subsequently install the non-

English message environment, as follows.

NOTE

Before Basic Operation Package 1 can be installed, operations such as

driver installation and setting must be performed according to the

operating environment. For details, refer to the following documents:

l Personal computer connected to High Speed Serial Bus Type 2, the

FS160i/180i/210i having personal computer functions, or Intelligent

Terminal Type 2

•• Release Note (README.TXT) on the driver library floppy disk

(A02B-0207-K730#ZZ07-1)

•• Release Note (README.TXT) on the driver disk (A02B-0207-

K791#ZZ07-1)

l NC Board

•• Lathe system

Release Note (README.TXT) on Disk 1 of the setup disks (A02B-

0234-H500)

•• Machining center system

Release Note (README.TXT) on Disk 1 of the setup disks (A02B-

0235-H500)
