B-62994EN/02 7. SYSTEM

-207-

• Flow control

Set the control method to be applied once the communication buffer is

full.

l Folder

When the channel is used for connection with a disk, set the data items

below.

• Path

Set the path of the data file used for input/output. To change the path,

click the button to select a new path.

• File type

Set the type of file to be used for input/output. To make a more

detailed file type specification, select "Extension," then specify the

desired extension.

l I/O data

• Input code

Set a character code system to be used for data input.

• Output code

Set a character code system to be used for data output.

• EOB code

Set a type of EOB code.

• Feed output

For output onto paper tape, feed codes can be output. Check this item

to output feed codes.

• TV check

A space code can be inserted into a data block for the TV check.

Check this item to enable the inserting of space for the TV check.

• CTV

This item is enabled when the TV check item is turned on. By

checking this item, a TV check in a comment can be cancelled.
