OPEN CNC (Basic Operation Package 1 for Windows95/NT) Operators manual Page 417

Operators manual
APPENDIX 1 REQUIRED NC SETTING FOR EACH BASIC OPERATION PACKAGE 1 SCREEN B-62994EN/02
-400-
27 P code Macro Variable Screen
FS16/18/21/NC Board :
Supported NC FS16/160-MB/TB/MMB/TTB, FS16/160-MC/TC/MMC/TTC, FS16i/160i-MA/TA
FS18/180-MB/TB/TTB, FS18/180-MC/TC/TTC, FS18i/180i-MA/TA
FS21/210-MB/TB, FS21i/210i-MA/TA
Option Macro executer
Size of main CPU custom software
Size of sub CPU custom software (when two-path control is used)
The following conditions must also be satisfied:
The object of P-CODE macro is loaded.
Executer parameter 9000#1 = 1
NC parameter setting or
NC mode relating to this
screen
Type of P-CODE variables 1
Always floating decimal point format.
Type of P-CODE variables 2
When "High-speed cycle cutting" option is NOT provided,
Compiling parameter 9002#3 = 0 Floating decimal point format (from 20000th)
= 1 Integer format (from 20000th)
When "High-speed cycle cutting" option is provided,
Integer format (from 200000th)
Number of P-CODE variables 1
(Value of compiling parameter 9037) × 100
Number of P-CODE variables 2
When "High-speed cycle cutting" option is NOT provided,
(Value of compiling parameter 9044) × 12 (for floating decimal point format)
(Value of compiling parameter 9044) × 30 (for integer format)
When "High-speed cycle cutting" option is provided,
65536 (Basic)
131071 (when "High-speed cycle data additional variables A" option is provided)
262143 (when "High-speed cycle data additional variables B" option is provided)
