7. SYSTEM B-62994EN/02
-216-
8. Click the <OK> button.
NOTE
l When the parameters output from a CNC are to be entered into
another CNC, the number of axes and option selection states of the
CNC that receives the parameters must match those of the CNC
from which the parameters are output.
For an explanation of the CNC parameter for the number of axes,
refer to the relevant manual provided with each CNC. For an
explanation of how to set the CNC parameter for the number of
axes, see Section 7.1, "Setting Parameters."
l Some CNC parameters are protected. Such parameters cannot be
modified using this screen. Use the parameter setting screen.
For an explanation of how to perform parameter setting, see Section
7.1, "Setting Parameters."
