7.9 Setting Spindle Tuning Data
This section describes how to set spindle tuning data.
Procedure
1. If the soft key is currently not displayed, press the function
selection key .
2. Press the soft key.
3. If the [Spindle Tuning] screen is currently not displayed, press the
chapter selection key .
4. If the soft key is currently not displayed, press the
soft key until the soft key is displayed.
Press the soft key.
The [Spindle Tuning] screen is displayed.
CAUTION
Spindle tuning data is set to match the characteristics of the machine
connected to the CNC. The spindle tuning data varies with the
machine; modifying this the data may disable the operation of the
machine, or degrade the precision of the machine. In general, the end
user must not attempt to modify the spindle tuning data.
NOTE
To set spindle tuning data, the respective CNC option is required.
The Power Mate-D/H and Power Mate i-H do not support the setting of
spindle tuning data.
