B-62994EN/02 6. SETTING
-189-
6.13 Tool Post Interference Check Settings
This section describes how to set tool post interference check data.
Procedure
1. If the soft key is currently not displayed, press the function
selection key .
2. Press the soft key.
3. If the [Tool Post Interference Check] screen is currently not displayed,
press the chapter selection key .
Press the soft key.
The [Tool Post Interference Check] screen appears.
NOTE
Tool post interference check data can be set only when
FS16/18/160/180-TTB/TTC, FS16i/18i/160i/180i-T (with the 2-path
control function), or FS15/150-TTB is used.
To set the tool post interference check data, the corresponding CNC
option is required.
To set the tool post interference check data, set the following status:
l Protect key
• Released
For an explanation of how to release the protect key, refer to the
manual supplied by the machine tool builder.
