B-62994EN/02 APPENDIX 4 SWITCHING THE MESSAGE LANGUAGE

-431-

• Message file

This binary file stores the messages that can be displayed. The message

file can be created by the message file generator provided with Basic

Operation Package 1. For an explanation of the procedure for creating

the message file, see Appendix 4, "Message File Generator."

• INI file

This text file stores the messages that can be displayed on the

[Parameter] screen and [Diagnosis] screen and the messages output upon

the occurrence of an NC alarm or PMC alarm. The messages can be

displayed in the desired language by replacing that part enclosed by a

pair of double quotation marks ("") with the desired language.

lAdding a desired language environment

A desired language environment can be added to the Basic Operation

Package either manually or by using ADDLANG.EXE, an installer.

• Manually adding a language environment

1. Create the message files and INI files for the desired language.

2. Create subfolders for storing the message files and INI files within

the folder of the Basic Operation Package.

3. Copy the message files and INI files into the subfolders created in

step 2, above.

4. Display the [Language Switcher Setting] screen. (For details of this

operation, see Section 11.4.1, "Installing message languages.")

NOTE

l The message files and INI files can be placed in a single folder

l The folders containing the English message files and English INI

files can neither be deleted nor renamed.

NOTE

Before adding a desired language environment, activate and

terminate Basic Operation Package 1 at least once. For an

explanation of how to activate and terminate Basic Operation

Package 1, see Section 2.1, "Starting and Terminating Basic

Operation Package 1."

This appendix describes the general procedure for adding a

language environment. For an explanation of the specific

procedure for adding a Japanese, German, French, Italian, or

Spanish environment, see Section 1.2, "Installing Basic

Operation Package 1."
