OPEN CNC (Basic Operation Package 1 for Windows95/NT) Operators manual Page 423

Operators manual
APPENDIX 1 REQUIRED NC SETTING FOR EACH BASIC OPERATION PACKAGE 1 SCREEN B-62994EN/02
-406-
33 Diagnosis Screen
FS16/18/21/NC Board :
Supported NC FS16/160-MB/TB/MMB/TTB, FS16/160-MC/TC/MMC/TTC, FS16i/160i-MA/TA
FS18/180-MB/TB/TTB, FS18/180-MC/TC/TTC, FS18i/180i-MA/TA
FS21/210-MB/TB, FS21i/210i-MA/TA
NC Board-M/T
Option None (Basic)
NC parameter setting or
NC mode relating to this
screen
None
FS15:
Supported NC FS15/150-MB/TB/TTB
Option None (Basic)
NC parameter setting or
NC mode relating to this
screen
None
Power Mate:
Supported NC Power Mate-D/H
Power Mate i-D/H
Option None (Basic)
NC parameter setting or
NC mode relating to this
screen
None
34 System Configuration Screen
FS16/18/21/NC Board :
Supported NC FS16/160-MB/TB/MMB/TTB, FS16/160-MC/TC/MMC/TTC, FS16i/160i-MA/TA
FS18/180-MB/TB/TTB, FS18/180-MC/TC/TTC, FS18i/180i-MA/TA
FS21/210-MB/TB, FS21i/210i-MA/TA
NC Board-M/T
Option None (Basic)
NC parameter setting or
NC mode relating to this
screen
None
FS15:
Supported NC FS15/150-MB/TB/TTB
Option None (Basic)
NC parameter setting or
NC mode relating to this
screen
None
Previous page
Next page
