OPEN CNC (Basic Operation Package 1 for Windows95/NT) Operators manual Page 398

Operators manual
B-62994EN/02 APPENDIX 1 REQUIRED NC SETTING FOR EACH BASIC OPERATION PACKAGE 1 SCREEN
-381-
FS15:
Supported NC FS15/150-MB/TB
Option Manual handle interruption
NC parameter setting or
NC mode relating to this
screen
Necessary setting to this screen
Refer to “Over All Position”.
Axis name
Refer to “Over All Position”.
Displayed/Not displayed of axis
Refer to “Over All Position”.
Switch between inch/metric
When “Inch/metric conversion” option is provided,
Parameter 0010#0 = 0 metric
= 1 inch
Display of mirror image of the axis data
Refer to “Over All Position”.
Display of soft key to “Cancel Manual Overlap”
Always displayed.
Power Mate:
Supported NC Power Mate-D/H
Power Mate i-D/H
Option Power Mate-H :Manual handle interruption
Power Mate-D, Power Mate i-D/H :None (Basic)
NC parameter setting or
NC mode relating to this
screen
Axis name
Refer to "Over All Position".
Displayed/Not displayed of axis
Refer to "Over All Position".
Switch between inch/metric
Parameter 0000#2 = 0 metric
= 1 inch
Display of mirror image of the axis data
Refer to "Over All Position".
Display of soft key to “Cancel Manual Overlap” (Power Mate i-D/H only)
Parameter 7100#3 = 1
Previous page
Next page
