6. SETTING B-62994EN/02

-180-

6.10 Chopping Data Settings

This section describes how to set chopping data.

Procedure

1. If the soft key is currently not displayed, press the function

selection key .

2. Press the soft key.

3. If the [Chopping] screen is currently not displayed, press the chapter

selection key .

Press the soft key.

The [Chopping] screen appears.

NOTE

The function for setting chopping data is supported only for machining

center systems.

To set the chopping data, the corresponding CNC option is required.

To set the chopping data, set the following status:

l Protect key

• Released

For an explanation of how to release the protect key, refer to the

manual supplied by the machine tool builder.
