OPEN CNC (Basic Operation Package 1 for Windows95/NT) Operators manual Page 390

Operators manual
B-62994EN/02 APPENDIX 1 REQUIRED NC SETTING FOR EACH BASIC OPERATION PACKAGE 1 SCREEN
-373-
FS15 :
Supported NC FS15/150-MB/TB/TTB
Option None (Basic)
NC parameter setting or
NC mode relating to this
screen
Necessary setting to this screen
Parameter 2204#1 = 1 Use machine position and absolute position
7613#0 = 1 Use dynamic display
7613#1 = 1 Use real speed display
7613#2 = 1 Use main spindle speed display
Axis name
Parameter 1020 = 88 X
= 89 Y
= 90 Z
= 85 U
= 86 V
= 87 W
= 65 A
= 66 B
= 67 C
Displayed/Not displayed of axis
Parameter 1004#6 = 0 Displayed
= 1 Not displayed
Switch between inch/metric (for Relative, Absolute, Distance to Go)
When “Inch/metric conversion” option is provided,
Parameter 0010#0 = 0 metric
= 1 inch
Switch between inch/metric (for Machine)
When “inch/metric conversion” option is provided,
Parameter 1002#0 = 0 metric
= 1 inch
Display of mirror image of the axis data
Parameter 0012#0 = 0 Not use mirror image
= 1 Use mirror image
Displayed/Not displayed of “Distance to Go”
Always displayed.
Display of soft key to “Set Float Point”
When “Floating reference position return” option is provided.
Display of soft key to “Preset Work Coord.”
Always displayed.
