7. SYSTEM B-62994EN/02

-248-

l Start condition/end condition

For the one-shot type, specify a sampling start condition.

• Start

Sampling is started by pressing the soft key.

• Start and trigger up

Sampling is started by pressing the soft key, then turning

on the signal specified with Trigger signal.

• Start and trigger down

Sampling is started by pressing the soft key, then turning

off the signal specified with Trigger signal.

For the servo alarm type, specify a sampling end condition.

⋅ Servo alarm

Sampling is terminated upon the detection of a servo alarm.

• Servo alarm or trigger up

Sampling is terminated upon the detection of a servo alarm or by

turning on the signal specified with Trigger signal.

• Servo alarm or trigger down

Sampling is terminated upon the detection of a servo alarm or by

turning off the signal specified with Trigger signal.

l Trigger signal

When the start condition/end condition is "trigger up" or "trigger

down," specify the PMC address and bit of the signal used as the

trigger, for example, as follows:

G0007.2

For information about the PMC addresses and bits of signals, refer to

the address table in the connection manual (BMI interface) provided

with the CNC.

l Sampling time/delay time

Specify a sampling time (for the one-shot type) or delay (for the servo

alarm type) in milliseconds.
