OPEN CNC (Basic Operation Package 1 for Windows95/NT) Operators manual Page 75

Operators manual
B-62994EN/02 5. NC PROGRAM
-57-
3. Select the NC program you want to get from the NC.
Click the <OK> button.
NOTE
When some modifications have been made to the NC
program already displayed on the NC program edit screen, a
prompt appears asking you whether you want to write the NC
program back to the CNC.
To write the NC program back to the CNC, click the <OK>
button. Perform a write operation by following the procedure
explained in Section 5.1.2, "Writing a program back to the NC."
When you don't want to write the NC program back to the CNC,
click the <Cancel> button. Then, the modified NC program is
discarded.
