OPEN CNC (Basic Operation Package 1 for Windows95/NT) Operators manual Page 222

Operators manual
7. SYSTEM B-62994EN/02
-204-
Explanation
l Data input/output
The currently selected input/output setting item (device), channel, data
input status, and remaining amount of free space (in bytes) at the
connection destination are displayed. On the right side of the screen, a
list of the data files of the connection destination is displayed, for
example, by pressing the [Directory] soft key.
The following items of data can be input and output:
• Programs
• Tool offset data
• Custom macro variables (common variables only)
• Parameters
• Pitch error compensation data
l Operation soft keys
Press the operation selection key .
The operation soft keys appear.
For details of each function, see the description below.
7.4.1 Setting parameters for input/output
This section describes how to set the parameters for the input/output of
different types of data.
Procedure
1. If the [Data I/O] screen is currently not displayed, display the [Data I/O]
screen as explained in Section 7.4, "Data Input/Output."
