OPEN CNC (Basic Operation Package 1 for Windows95/NT) Operators manual Page 394

Operators manual
B-62994EN/02 APPENDIX 1 REQUIRED NC SETTING FOR EACH BASIC OPERATION PACKAGE 1 SCREEN
-377-
FS15:
Supported NC FS15/150-MB/TB/TTB
Option None (Basic)
NC parameter setting or
NC mode relating to this
screen
Necessary setting to this screen
Refer to “Over All Position”.
Axis name
Refer to “Over All Position”.
Displayed/Not displayed of axis
Refer to “Over All Position”.
Switch between inch/metric
Refer to “Over All Position”.
Display of mirror image of the axis data
Refer to “Over All Position”.
Power Mate:
Supported NC Power Mate-D/H
Power Mate i-D/H
Option None (Basic)
NC parameter setting or
NC mode relating to this
screen
Axis name
Refer to "Over All Position".
Displayed/Not displayed of axis
Refer to "Over All Position".
Switch between inch/metric
Refer to "Over All Position".
Display of mirror image of the axis data
Refer to "Over All Position".
Display of soft key to "Set Floating Reference"
Not displayed
Display of soft key to "Preset Workpiece Coord."
Not displayed
Previous page
Next page
