OPEN CNC (Basic Operation Package 1 for Windows95/NT) Operators manual Page 430

Operators manual

Page of 462

/ 462

B-62994EN/02 APPENDIX 1 REQUIRED NC SETTING FOR EACH BASIC OPERATION PACKAGE 1 SCREEN

-413-

Power Mate:

Supported NC Power Mate i-D

Option Spindle serial output

Spindle orientation

Rigid tapping

Spindle Name

First spindle F64#1 = 0 Displayed as "S11"

= 1 Displayed as "S12"

Select Gear

Changed by the combination of the PMC signals, "CTH1" and "CTH2".

CTH1 CTH2 Display

0 0 1.High

0 1 2.Mid.High

1 0 3.Mid.Low

1 1 4.Low

Operation mode

Changed by the NC program execution. The displayed "Operation Mode" is one of

the followings.

"Speed Control"

"Orientation",

"Sync. Control",

"Rigid Tapping"

Type of speed display

Parameter 4001#2 = 1

"Spindle speed (rpm)" is displayed.

Spindle Tuning Parameter

Changed by the "Operation Mode".

Contents Condition

Proportional gain Basic

Integral gain Basic

Loop gain Except "Speed Control" mode

Motor voltage Basic

ORAR gain "Orientation" mode

Regenerative power

Stop position shift

Acc./Dcc. time constant

ZRN gain

"Speed Control" mode

"Orientation" mode

"Sync. Control" mode

Except the above-mentioned types of "Operation Mode"

Reference position shift Except "Speed Control" mode

NC parameter setting or

NC mode relating to this

screen

∗ One of "Regenerative power", "Stop position shift", "Acc./Dcc. time constant", "ZRN gain"

is displayed according to the "Operation Mode".
