B-62994EN/02 APPENDIX 1 REQUIRED NC SETTING FOR EACH BASIC OPERATION PACKAGE 1 SCREEN
-385-
FS15:
Supported NC FS15/150-MB/TB/TTB
Option None (Basic)
NC parameter setting or
NC mode relating to this
screen
Display of soft key to “Teach in”
When “Playback” option is provided and NC is in Teach in Handle or Teach in JOG mode.
Power Mate:
Supported NC Power Mate-D/H
Power Mate i-D/H
Option None (Basic)
NC parameter setting or
NC mode relating to this
screen
Display of soft key to "Teach in"
When NC is in Teach in Handle or Teach in JOG mode
12 MDI Program Screen
FS16/18/21/NC Board :
Supported NC FS16/160-MB/TB/MMB/TTB, FS16/160-MC/TC/MMC/TTC, FS16i/160i-MA/TA
FS18/180-MB/TB/TTB, FS18/180-MC/TC/TTC, FS18i/180i-MA/TA
FS21/210-MB/TB, FS21i/210i-MA/TA
NC Board-M/T
Option None (Basic)
NC parameter setting or
NC mode relating to this
screen
None
FS15:
Supported NC FS15/150-MB/TB/TTB
Option None (Basic)
NC parameter setting or
NC mode relating to this
screen
None
Power Mate:
Supported NC Power Mate-D/H
Power Mate i-D/H
Option None (Basic)
NC parameter setting or
NC mode relating to this
screen
None
Previous page
Next page
