OPEN CNC (Basic Operation Package 1 for Windows95/NT) Operators manual Page 251

Operators manual
B-62994EN/02 7. SYSTEM
-233-
7.5 Setting Pitch Error Compensation Data
This section describes how to set pitch error compensation data.
Procedure
1. If the soft key is currently not displayed, press the function
selection key .
2. Press the soft key.
3. If the [Pitch Error Compensation] screen is currently not displayed,
press the chapter selection key .
CAUTION
Pitch error compensation data is set to match the characteristics of
the machine connected to the CNC. The pitch error compensation
data varies with the machine; modifying this data may degrade the
precision of the machine. In general, the end user must not attempt to
modify the pitch error compensation data.
NOTE
The Power Mate-D/H and Power Mate i-H do not support the setting of
pitch error compensation data.
To set pitch error compensation data, establish the following status:
l Setting data
• Enable Parameter Write.
l Operation
• Emergency stop
For an explanation of how to specify the setting data, see Section 6.1,
"Setting Data."
