B-62994EN/02 11. CUSTOMIZATION

-359-

Explanation

The following types of message language customization can be performed:

l Installing new message languages

l Changing the order in which message languages are listed

l Uninstalling message languages

For details, see the description below.

11.4.1 Installing message languages

This section describes how to install message languages in Basic Operation

Package 1.

Once two or more message languages have been installed in Basic Operation

Package 1, switching between these languages is enabled.

Procedure

1. If the [Language Switcher Setting] screen is currently not displayed,

follow the procedure shown in Section 11.4, "Customizing Message

Languages" to display the [Language Switcher Setting] screen.
