B-62994EN/02 APPENDIX 2 BACKING UP THE SETTING FILE
-419-
APPENDIX 2BACKING UP THE SETTING FILE
This section describes the setting file.
The settings for Basic Operation Package 1 are stored at the location
indicated below. A backup copy of the original information should be kept to
guard against errors.
l Storage location of the WIN32 version
[HKEY_CURRENT_USER\Software\VB and Program Settings\WinBOP?]
key and [HKEY_CURRENT_USER\Software\VB and Program
Settings\WinBOPl?] key of the registry (? represents a numeric or blank
character.)
The registry file can be saved by choosing [Registry] and [Export
Registry File ...] of the registry editor (REGEDIT.EXE) in the Windows
directory.
l Storage location of the WIN16 version
WINBOP.INI and WINBOPL.INI files in the Windows directory
