B-62994EN/02 5. NC PROGRAM
-77-
5.2 Editing an MDI Program
This section explains how to edit an MDI program.
Procedure
1. If the soft key is currently not displayed, press the function
selection key .
2. Press the soft key.
3. If the [MDI Program] screen is currently not displayed, press the
chapter selection key .
Press the soft key.
The [MDI Program] screen appears.
WARNING
After editing an MDI program, never attempt to machine a workpiece
without first checking the operation of the machine. Before starting
the machine, check that the programmed values, compensation
values, current position, and external signal settings are correct.
NOTE
To edit an MDI program, set the following status:
l Operation
• Stopped or paused in MDI mode
To change the CNC operating mode from the software operator's
panel, see Section 6.7, "Software Operator's Panel Settings."
