1. SETUP B-62994EN/02

-6-

•• Installing the non-English message environment

1. Insert the disk (A02B-0207-K750#ZZ07-9) into the floppy disk

drive.

2. Click the [Start] button.

(For Windows 3.1, select [File].)

3. Select [Run].

4. Enter the data corresponding to the target language as listed below,

then click the <OK> button.

Japanese <drive-name> : \JPN\ADDLANG

German <drive-name> : \GER\ADDLANG

French <drive-name> : \FRE\ADDLANG

Italian <drive-name> : \ITA\ADDLANG

Spanish <drive-name> : \SPA\ADDLANG

<drive-name> is the name of the 3.5-inch floppy disk drive.

5. Perform installation according to the displayed messages.

NOTE

Before installing the non-English message environment, start

and terminate Basic Operation Package 1 at least once. For an

explanation of how to start and terminate Basic Operation

Package 1, see Section 2.1, "Starting and Terminating Basic

Operation Package 1."
