B-62994EN/02 6. SETTING

-121-

6.2 Operating Time, Parts Count, and Timer Settings

This section describes how to set the Operating time, Parts count, and Timer.

Procedure

1. If the soft key is currently not displayed, press the function

selection key .

2. Press the

soft key.

3. If the [Setting (Timer)] screen is currently not displayed, press the

chapter selection key .

Press the soft key.

The [Setting (Timer)] screen appears.

NOTE

To set the operating time, parts count, and timer, first establish the

following status:

l Operation

Set either of the following statuses:

• Emergency stop

• Stopped or paused in MDI mode

l Protect key

• Released

⋅

To change the CNC operating mode from the software operator's

panel, see Section 6.7, "Software Operator's Panel Settings."

For an explanation of how to release the protect key, refer to the

manual supplied by the machine tool builder.
