OPEN CNC (Basic Operation Package 1 for Windows95/NT) Operators manual Page 16

Operators manual
B-62994EN/02 PREFACE
p-3
Contents of the Product Package
This product package consists of the following:
lFloppy disks
FANUC Basic Operation Package 1 (A02B-0207-K750#ZZ07)
Organization of This Manual
This manual is organized as follows:
SAFETY PRECAUTIONS
Explains the general precautions which must be observed to ensure safety
when using Basic Operation Package 1.
PREFACE
Briefly explains the features of Basic Operation Package 1. Also explains
how to use information on the usage of Basic Operation Package 1,
including this manual.
1. SETUP
Explains how to set up the environment for using Basic Operation
Package 1 and how to prepare Basic Operation Package 1 for use.
2. BASIC KNOWLEDGE
Provides basic information with which the user should be familiar before
attempting to use Basic Operation Package 1.
3. SETTING THE PARAMETERS REQUIRED TO USE BASIC OPERATION
PACKAGE 1
Explains how to set the parameters required to display the screens of
Basic Operation Package 1.
4. POSITION DISPLAY
Explains how to display positions, such as the current position, for the
program that is currently being executed.
5. NC PROGRAM
Explains how to display, edit, and check NC programs.
6. SETTING
Explains how to set data.
NOTE
Read the Release Note (README.TXT), provided on the first floppy
disk of the product package. It provides detailed information on this
product package and information not described in the operator's
manual.
