OPEN CNC (Basic Operation Package 1 for Windows95/NT) Operators manual Page 382

Operators manual

Page of 462

/ 462

11. CUSTOMIZATION B-62994EN/02

-364-

11.5 Customizing Alarm Messages

This section describes how to customize the alarm messages to be displayed

on a screen.

An alarm message can be customized by describing the alarm number and

corresponding message in the alarm message setting file.

When an alarm condition occurs, its alarm number and alarm message are

displayed if they are described in the setting file.

If this description is not contained in the setting file, an alarm message

obtained from the CNC is displayed.

The names and types of the alarm message setting files are as follows:

l Names and types of alarm message setting files

Setting file name Setting file type

ALARM16M.INI

For FS16/18/21/160/180/210-M series,

NC Board-M series

ALARM16T.INI

For FS16/18/21/160/180/210-T series,

NC Board-T series

ALARM15M.INI

For FS15/150-M series

ALARM15T.INI

For FS15/150-T series

ALARMPM.INI

For Power Mate

During Basic Operation Package 1 installation, these setting files are

stored into the INI folder subordinate to the folder in which Basic

Operation Package 1 is installed.

l Description format in the alarm message setting file

The description format in the alarm message setting file is as follows:

[ALARM]

alarm-number="message-text"

......................................................

NOTE

Before alarm message customization, it is recommended that a

backup of the alarm message setting file be made to guard

against data loss.
