Open CNC Basic Operation Package 2 Operators manual Page 109

Operators manual
B-63924EN/01 2.STANDARD OPERATION
- 89 -
2.3.4.12 Pasting character strings to an NC program
In the NC program being edited, character strings cut or copied by
[Cut] or [Copy] can be pasted at a specified position.
Procedure
1 If the [Program Edit] screen is currently not displayed, display
the [Program Edit] screen as described in Subsection 2.3.4,
"Editing an NC Program".
2 Press the display/operation switching key
to display the
operation keys.
3 Move the cursor to a position where the data is to be pasted.
4 Press the operation key
, the [Insert] key on the
keyboard, or the [INSERT] key on the MDI panel. The
character string or character strings obtained by [Cut] or [Copy]
are inserted at the cursor position.
