Open CNC Basic Operation Package 2 Operators manual Page 156

Operators manual
2.STANDARD OPERATION B-63924EN/01
- 136 -
Procedure
1 If the [Work Zero Offset] screen is currently not displayed,
display the [Work Zero Offset] screen by pressing the
[SETTING] function key and [WORK OFS] submenu key.
2 Press the display/operation switching key
to display the
operation keys.
3 Select workpiece origin offset data to be set.
4 Enter a desired value through the keyboard or MDI panel.
To enter a measured value, see Subsection 2.4.5.2, "Entering a
measured value for workpiece origin offset data".
To enter an increment, see Subsection 2.4.5.3, "Entering an
increment for workpiece origin offset data".
