Open CNC Basic Operation Package 2 Operators manual Page 148

Operators manual
2.STANDARD OPERATION B-63924EN/01
- 128 -
2.4.4 Setting a Custom Macro Variable
The value of a custom macro variable can be displayed and set.
This screen can be displayed by pressing the [SETTING] function key
and [MACRO] submenu key.
WARNING
Incorrect use or setting of a custom macro variable
may result in unpredictable movement of the
machine, resulting in damage to the workpiece, the
machine itself, or injury to the operator or
bystanders.
Set custom macro variable values that are
appropriate for the machining program.
CAUTION
Applied when there is a danger of the equipment
being damaged, if the approved procedure is not
observed.
NOTE
To set a custom macro variable, the
corresponding CNC option is required.
Moreover, set the following status:
• Protect key
- Released
For the release of the protect key, refer to the
relevant operator's manual of the machine tool
builder.
Three types of custom macro variables are used:
Type of
variable
Variable range Description
Local
variable
#1 to #33 Custom macro variables of this type
cannot be set but can be only displayed
on this screen.
Common
variable 1
#100 to #199
(*1)
Custom macro variables of this type can
be displayed and set on this screen.
The values of custom macro variables
of this type are cleared when the power
is turned off.
Common
variable 2
#500 to #999
(*1)
Custom macro variables of this type can
be displayed and set on this screen.
The values of custom macro variables
of this type are preserved when the
power is turned off.
*1 The actually usable range depends on the CNC option.
