Open CNC Basic Operation Package 2 Operators manual Page 40

Operators manual
2.STANDARD OPERATION B-63924EN/01
- 20 -
The table below indicates the screens displayed when you press the
keys of the operation key controls, and also indicates the operable
functions on each screen.
Function
key
Submenu
key
Screen displayed Operation
key
Function executed
Resets coordinates.
Presets relative coordinates.
Sets the floating reference position.
Overall Position
Presets the workpiece coordinate system.
Modal
Actual Speed
Sets the floating reference position.
Absolute
Presets the workpiece coordinate system.
Modal
Actual Speed
Resets relative coordinates.
Presets relative coordinates.
Sets the floating reference position.
Relative
Presets the workpiece coordinate system.
Modal
Actual Speed
