B-63924EN/01 2.STANDARD OPERATION
- 97 -
2.3.6 DNC Schedule Operation
In DNC schedule operation, NC programs are prepared on the hard
disk of the personal computer, and data such as the names of programs,
the order of operation, and the number of repeats is stored on a file
called a schedule file beforehand. Then, the NC programs are sent
sequentially as scheduled to the CNC from the personal computer
according to the start signal of the CNC.
NOTE
A schedule file, NC programs, and the folders
storing them must be made readable and writable
beforehand after checking their access rights and
attributes. If an unpredictable error occurs, the
files and folders can be destructed.
To perform a DNC schedule operation, the following parameter needs
to be set:
Meaning Setting
Selecting HSSB for the I/O device No. 0020 → 15
NOTE
• Set CNC parameters to perform a DNC operation
normally.
• Enable DNC operation to perform a DNC operation
and to display the [DNC Schedule Setting] screen,
the [DNC Sub Program Call Setting] screen, and
the [DNC Operation Monitor] screen. For details,
see Subsection 2.7.2.1, "Setting a CNC to be
connected".
• Before performing a DNC operation, make a setting
to meet the environment used. For details, see
Section 3.9, "CUSTOMIZING DNC OPERATION".
