Open CNC Basic Operation Package 2 Operators manual Page 306

Operators manual
3.CUSTOMIZATION B-63924EN/01
- 286 -
On the [Parameter] screen, the size of a control defined in the
controlbase tag is that required to display one piece of parameter
information.
• forecolor in the font tag in the controlbase tag
forecolor type index attribute number
Basic font color 0
Font color used in editing 1
Font color for the parameter
number representing a parameter
that requires restart after update
2
Display based on one data_series tag
Height defined in the size
tag in the controlbase tag
Width defined in the size tag in the controlbase tag
