Open CNC Basic Operation Package 2 Operators manual Page 142

Operators manual
2.STANDARD OPERATION B-63924EN/01
- 122 -
2.4.3.1 Switching the type of tool offset data
A type of tool offset data to be set and displayed can be selected.
Procedure
1 If the [Tool Offset] screen is currently not displayed, display the
[Tool Offset] screen as described in Subsection 2.4.3, "Setting
Tool Offset".
2 Press the display/operation switching key
to display the
operation keys.
3 Select a type of tool offset data by pressing the operation key
or when using the lathe system, or the
operation key
or when using the machining
center system.
NOTE
The selectable types of data differ between the
lathe system and the machining center system:
- Lathe system: Geometry and wear
- Machining center system: Tool length and
tool radius
Depending on the CNC option, these soft keys
may not be displayed.
