action: opcmnd (executing a command)
In the above example, the [Setup] screen is started in response to a
command name of setup.
This way, defining command names listed below can start a wide
range of operations.
Command
name
Description Parameter
“fmcls” Closes all currently
displayed child screens.
None
“fmsel”
Switches active child
screens.
1 (for specifying the
name of a child screen to
be activated)
“setup” Starts the [Setup] screen. None
“lngsel” Switches display
languages.
None
“exit” Exits BOP2. None
“selfolder” Selects a reference folder. None
“aboutdisp” Displays a dialog for
BOP2 version information.
None
“cncsel” Gives focus to the CNC
select combo box.
None
“keydisp” Executes display
switching for a specified
key control.
1 (the index of the target
key control, starting at
number 0, is set up.)
Operating commands on child screens requires setting the usage
attribute in the funcdef tag to import. Use the following definitions.
<funcs>
:
<action>
<opcmnd>
<command>setup</command>
</opcmnd>
</action>
:
</funcs>
