Open CNC Basic Operation Package 2 Operators manual Page 161

Operators manual
B-63924EN/01 2.STANDARD OPERATION
- 141 -
• [Relative] and [Absolute] screens
Relative position and absolute position data is displayed.
For operation, see Section 2.2, "POSITION DISPLAY".
Procedure
1 If the [Work Shift] screen is currently not displayed, display the
[Work Shift] screen by pressing the [SETTING] function key and
[W.Shift] submenu key.
2 Press the display/operation switching key
to display the
operation keys.
3 Select a workpiece coordinate system shift to be set.
4 Enter a desired value through the keyboard or MDI panel.
To specify a shift value directly, set the desired value in "Shift
value".
To specify a shift value indirectly from a measured value, set a
measured distance from the coordinate system origin in
"Measurement".
A displacement from the set coordinate system origin is
calculated, and a shift value is set accordingly.
To enter an increment, see Subsection 2.4.6.1, "Entering an
increment for workpiece coordinate system shift data".
