2.STANDARD OPERATION B-63924EN/01
- 72 -
2.3.3.12 Deleting a folder from the CNC
A folder on the CNC can be deleted.
NOTE
To delete a folder from the CNC, set the following
status:
• Protection of the target folder released
• Target folder made empty
• Operation
- Stopped
Procedure
1 If the [Program Edit] screen is currently not displayed, display
the [Program Edit] screen as described in Subsection 2.3.3,
"Displaying the NC Program Directory".
2 Press the display/operation switching key
to display the
operation keys.
3 Select a folder to be deleted.
4 Press the operation key to display the [Program Edit -
Delete Folder] screen.
5 Click the <OK> button to delete the folder.
