Open CNC Basic Operation Package 2 Operators manual Page 265

Operators manual
B-63924EN/01 3.CUSTOMIZATION
- 245 -
3.5.3.1 text definitions
The text tag allows you to define a caption to be displayed.
The following two methods can be used to define captions.
1. Directly defining a caption in the text tag
By this method, you can define a caption directly in the text tag.
The caption is fixed even when display languages are switched.
If you want to have captions fixed, use this method. If you need
to switch display languages, use method 2.
2. Specifying a caption, using text from a resource file
You can get text from a resource file and use it as a caption.
The resource file contains text supporting different languages.
This definition method supports language switching.
Method 1 takes precedence if the text tag contains directly
defined text.
<text>
<resource>m_pos</resource>
<message>MSG_POS_TITLE_OVR</message>
</text>
<text>Overall Position Display</text>
