B-63924EN/01 APPENDIX A.SCREEN-SPECIFIC CNC SETTINGS
- 335 -
18. [System Configuration] screen
CNC supported FS30i/31i/32i
Optional function None (basic)
Settin
g
s re
q
uired
for screen dis
p
la
y
modification and
operation
None
19. [Data I/O] screen
CNC supported FS30i/31i/32i
Optional function None (basic)
Settin
g
s re
q
uired
for screen dis
p
la
y
modification and
operation
Output of program data
When the 8-level data protection function is disabled, or
When the 8-level data
p
rotection function is enabled and the o
p
eration
level is not lower than the output protect level
Output of parameter data
When the 8-level data protection function is disabled, or
When the 8-level data protection function is enabled and the o
p
eration
level is not lower than the output protect level
Output of pitch error compensation data
When the 8-level data protection function is disabled, or
When the 8-level data protection function is enabled and the o
p
eration
level is not lower than the output protect level
Output of custom macro variable data
When the 8-level data protection function is disabled, or
When the 8-level data
p
rotection function is enabled and the o
p
eration
level is not lower than the change protect level
20. [Pitch] screen
CNC supported FS30i/31i/32i
Optional function Stored pitch error compensation
Settin
g
s re
q
uired
for screen dis
p
la
y
modification and
operation
Operation error protection function "incremental input recheck"
Bit 0 of parameter No. 10330 = 0 Displayed
= 1 Not displayed
Modification to pitch error compensation data
When the 8-level data protection function is disabled, or
When the 8-level data protection function is enabled and the o
p
eration
level is not lower than the change protect level
21. [PMC Status] screen
CNC supported FS30i/31i/32i
Optional function None (basic)
Settin
g
s re
q
uired
for screen dis
p
la
y
modification and
operation
Display of the [Switch PMC] operation key
When multiple PMC paths are used
Previous page
Next page
