Open CNC Basic Operation Package 2 Operators manual Page 169

Operators manual
B-63924EN/01 2.STANDARD OPERATION
- 149 -
2.5.2.1 Finding a diagnostic data number
The diagnostic data of a specified number can be displayed.
Procedure
1 If the [Diagnosis] screen is currently not displayed, display the
[Diagnosis] screen as described in Subsection 2.5.2, "Displaying
the Diagnosis Screen".
2 Press the display/operation switching key
to display the
operation keys.
3 Press the operation key
to display the [Diagnosis -
Number Search] screen.
4 Enter a diagnostic data number to be found, then click the <OK>
button.
NOTE
If the diagnostic data of a specified number is not
found, the diagnostic data of the greatest number
under the specified number is displayed.
