Open CNC Basic Operation Package 2 Operators manual Page 14

Operators manual
PREFACE B-63924EN/01
p-8
NOTATION CONVENTIONS
The following explains the notation conventions used in this manual:
• Menu, command, and screen notations
Example Explanation
[File] menu Menu names are enclosed in brackets [ ].
[Setting...] Command names are enclosed in brackets
[ ].
[Program Edit] screen Screen names (displayed on the title bars)
are enclosed in brackets [ ].
<OK> button Command buttons on the display are
enclosed in angle brackets < >.
• Key notations and operation
Example Explanation
[Enter] key Key names are enclosed in brackets [ ].
[Ctrl]+[Tab] keys When keys are to be pressed and held down
sequentially, the keys are indicated by
connecting them with +, as shown on the left.
Direction keys The [→], [←], [↑], and [↓] keys are collectively
called the direction keys.
• Mouse operations
Example Explanation
Click Press a mouse button, then release it immediately.
Double-click Click a mouse button twice in quick succession.
Drag Move the mouse while holding down a mouse
button, then release the button at a desired location.
• Folders
This manual refers to directories and folders collectively as folders.
• Sample screens
The screens shown in this manual are examples of the standard
system supplied by FANUC. Note that the screen layouts and
displayed file names may vary with the equipment being used and
according to customization.
Soft keys or screens are not displayed if the equipment being used
does not support the corresponding functions (for example, some
functions are supported only by machining center systems) or if the
CNC options for the corresponding functions are not installed.
Soft keys or screens are not displayed if the equipment being used
does not support the corresponding functions (for example, some
functions are supported only by machining center systems) or if the
CNC options for the corresponding functions are not installed.
• CNC units
Unless otherwise specified, CNC refers to the FS30i/31i/32i, while
FS30i refers to the FS30i/31i/32i.
