B-63924EN/01 APPENDIX A.SCREEN-SPECIFIC CNC SETTINGS
- 329 -
12. [Tool Offset] screen
CNC supported FS30i/31i/32i
Optional function None (basic)
Settin
g
s re
q
uired
for screen dis
p
la
y
modification and
operation
Axis name
See the [Overall Position] screen.
Inch/metric switching
When the "inch/metric switching" option is specified
Bit 2 of parameter No. 0000 = 0 Metric
= 1 Inch
Display of the [Clear] operation key
Bit 4 of parameter No. 3205 = 0 Displayed
= 1 Not displayed
Modification to tool offset data
When the 8-level data protection function is disabled, or
When the 8-level data
p
rotection function is enabled and the o
p
eration
level is not lower than the change protect level
Display of memory type A (M series)
Basic function
Display of memory type B (M series)
When the "tool compensation memory B" option is specified
Display of memory type C (M series)
When the "tool compensation memory C" option is specified
Display of virtual tool tip direction (M series)
When the "cutter/tool-nose radius compensation" option is specified
Bit 5 of parameter No. 5009 = 1 TIP
Display of 32 tool offsets (M series)
Basic function
Display of 64 tool offsets (M series)
When the "tool offset count 64" option is specified
Display of 99 tool offsets (M series)
When the "tool offset count 99" option is specified
Display of 200 tool offsets (M series)
When the "tool offset count 200" option is specified
Display of 400 tool offsets (M series)
When the "tool offset count 400" option is specified
Display of 499 tool offsets (M series)
When the "tool offset count 499" option is specified
Display of 999 tool offsets (M series)
When the "tool offset count 999" option is specified
Display of the [Length] and [Radius] operation keys (M series)
When the "tool compensation memory C" option is specified
