3.5.5.14 Custom Macro screen-specific definitions
Two types of definition files are used for this screen.
• “custommacro.xml”
This file is used to clarify a CNC to be connected when more
than one screen is displayed simultaneously. It can be renamed
at your discretion.
This file name is used in navigation file registration.
More than one file that is equivalent to “custommacto.xml” can
be created.
The definitions valid in the “custommacto.xml” include the
datatype and target tag definitions in the formCommon tag.
Files other than “custommacro.xml” are grouped by CNC type.
• “custommacro16.xml”
This is a definition file for the FS30i. This file name is fixed;
the file cannot be renamed.
NOTE
The name of this definition file is fixed; it cannot
be renamed. The layout and size are fixed for
individual CNC types separately.
The datatype and target tag definitions in the
“custommacro16.xml” file are dummies, but they are always
needed
<?xml version="1.0" encoding="utf-16"?>
<bop2:ScreenDef xmlns:bop2="http://www.fanuc.co.jp/bop2">
<formCommon>
<datatype>f_custommacro</datatype>
<target>0</target>
</formCommon>
