A.SCREEN-SPECIFIC CNC SETTINGS APPENDIX B-63924EN/01
- 336 -
22. [PMC Alarm] screen
CNC supported FS30i/31i/32i
Optional function None (basic)
Settin
g
s re
q
uired
for screen dis
p
la
y
modification and
operation
None
23. [PMC Counter] screen
CNC supported FS30i/31i/32i
Optional function None (basic)
Settin
g
s re
q
uired
for screen dis
p
la
y
modification and
operation
Display of the [Switch PMC] operation key
When multiple PMC paths are used
Display of PMC counter data
→ When the 8-level data protection function is enabled
Displayed unconditionally
→ When the 8-level data protection function is disabled
When the programmer function is enabled (K900.1 = 1), or
When PMC parameter reference is disabled (K902.6 = 0)
Editing of PMC counter data
→ When the 8-level data protection function is enabled
When the operation level is not lower than the change protect level
→ When the 8-level data protection function is disabled
- MDI mode
- When the programmer function is enabled (K900.1 = 1), or
When PMC parameter modification is disabled (K902.7 = 0)
24. [PMC Timer] screen
CNC supported FS30i/31i/32i
Optional function None (basic)
Settin
g
s re
q
uired
for screen dis
p
la
y
modification and
operation
Display of the [Switch PMC] operation key
When multiple PMC paths are used
Display of PMC timer data
→ When the 8-level data protection function is enabled
Displayed unconditionally
→ When the 8-level data protection function is disabled
When the programmer function is enabled (K900.1 = 1), or
When PMC parameter reference is disabled (K902.6 = 0)
Editing of PMC counter data
→ When the 8-level data protection function is enabled
When the operation level is not lower than the change protect level
→ When the 8-level data protection function is disabled
- MDI mode
- When the programmer function is enabled (K900.1 = 1), or
When PMC parameter modification is disabled (K902.7 = 0)
