Open CNC Basic Operation Package 2 Operators manual Page 43

Operators manual
B-63924EN/01 2.STANDARD OPERATION
- 23 -
Replaces a character string in an NC
program with another character string.
Cuts character strings from an NC
program.
Copies character strings from an NC
program.
Pastes character strings cut or copied by
[Cut] or [Copy] at a specified location in the
NC program.
Displays the top of an NC program.
Displays the end of an NC program.
Enters the current position.
Inserts the machine time.
Finds a character string in an MDI
program.
Replaces a character string in an MDI
program with another character string.
Sends an edited MDI program to the CNC.
Displays the top of an MDI program.
Displays the end of an MDI program.
Cuts character strings from an MDI
program.
MDI Program
Copies character strings from an MDI
program.
Previous page
Next page
