Open CNC Basic Operation Package 2 Operators manual Page 277

Operators manual
B-63924EN/01 3.CUSTOMIZATION
- 257 -
• forecolor
This item allows you to define a font color.
Use RGB color values in definitions. The red, green, and blue
tags correspond to the red, green, and blue components,
respectively. Each RGB color value can range between 0 and
255.
For some child screen types, it is possible to use more than one
forecolor tag.
For explanations about what font color the forecolor index attribute
corresponds to, see descriptions about individual child screens.
<font>
<name>MS Gothic</name>
<style>bold</style>
<size>12</size>
< index="0" is Basic Color -->
<forecolor bop2:index="0">
<red>0</red>
<green>0</green>
<blue>0</blue>
</forecolor>
< index="1" is Edit Color -->
<forecolor bop2:index="1">
<red>255</red>
<green>0</green>
<blue>0</blue>
</forecolor>
< index="2" is ReStart Color -->
<forecolor bop2:index="2">
<red>0</red>
<green>0</green>
<blue>255</blue>
</forecolor>
<
/font
>
