B-63924EN/01 3.CUSTOMIZATION
- 251 -
• backcolor
This item allows you to define the background color of a control.
Use RGB color values in definitions. The red, green, and blue
tags correspond to the red, green, and blue components,
respectively. Each RGB color value can range between 0 and
255.
If no color is specified, the definition in the status.xml is
reflected on the background color. For details, see Section 3.8,
“CUSTOMIZING THE PMC STATUS DISPLAY AREA”.
• panelbackcolor
This item allows you to define the default background color of a
panel.
Use RGB color values in definitions. The red, green, and blue
tags correspond to the red, green, and blue components,
respectively. Each RGB color value can range between 0 and
255.
If no color is specified, the definition in the status.xml is
reflected on the background color. For details, see Section 3.8,
“CUSTOMIZING THE PMC STATUS DISPLAY AREA”.
• font
This item allows you to define a font used in a control.
For details, see Subsection 3.5.4.6, “font definitions”.
• location
This item allows you to define the position of the top left corner
of a PMC status display.
The left and top tags correspond to the positions of the PMC
status display represented in pixels, respectively, along the
horizontal and vertical axes.
• size
This item allows you to define the size of a control.
The width and height tags correspond to the width and height of
the control represented in pixels, respectively.
• timerinterval
This item allows you to define a timer update interval in ms units.
If a value of 0 or lower is defined, no timer-triggered display
update takes place.
NOTE
The forecolor tag is not used.
