3.CUSTOMIZATION B-63924EN/01
- 306 -
3.6.3 Selecting Status Display Items
The commonstatus tag can be used to select what to display on the
status bar.
• commonstatus
Changing the value of each element listed below can specify
whether to display the respective items.
To display an item, select "True" for it. To hide an item, select
"False" for it.
Display select item Element Value
CNC system number head visible "True" / "False"
Selected program
name
program visible "True" / "False"
Sequence number sequence visible "True" / "False"
Current time time visible "True" / "False"
CNC switching cncswitch visible "True" / "False"
<?xml version="1.0" encoding="utf-16"?>
<status>
:
<commonstatus>
<head visible="False" />
<program visible="True" />
<sequence visible="True" />
<time visible="True" />
<cncswitch visible="True" />
</commonstatus>
:
</status>
