Open CNC Basic Operation Package 2 Operators manual Page 152

Operators manual
2.STANDARD OPERATION B-63924EN/01
- 132 -
2.4.4.3 Entering an increment for a custom macro variable
An increment can be entered for the value of a custom macro variable.
Procedure
1 If the [Custom Macro] screen is currently not displayed, display
the [Custom Macro] screen as described in Subsection 2.4.4,
"Setting a Custom Macro Variable".
2 Press the display/operation switching key
to display the
operation keys.
3 Select a custom macro variable to be set.
4 Press the operation key
to display the [Custom Macro
- +Input] screen.
5 Enter an incremental value (increment) then click the <OK>
button. The value obtained by adding the entered increment to
the current value is set.
