B-63924EN/01 2.STANDARD OPERATION
- 201 -
2.7 CONFIGURATION
This section explains the method of setting for general operation of
Basic Operation Package 2.
2.7.1 User Level and Password
Basic Operation Package 2 is configured so that two user interfaces
for operating the CNC can be set and one of the interfaces can be
selected to meet a user level.
• Level 1: Operator level
Level for operating the CNC on the production line. Usually,
only simple operations such as operation state checking are
performed.
• Level 2: Administrator level
Level for the administrator of a machine tool builder, service
organization, and so forth who needs to use all CNC functions.
This level is required to set parameters.
An operator can execute only a limited range of operations. The
administrator level allows all operations to be performed. To allow
only limited users to set or modify setting items, a password is set.
The password "fanuc" (half-size characters in lowercase) is set before
shipment. The password can be changed on the [Setup] screen. So,
the system administrator should change the password to an appropriate
one and exercise strict control on the new password.
