2.STANDARD OPERATION B-63924EN/01
- 118 -
On this screen, the following data items can be displayed and set:
Name Description
Parts total Indicates a cumulative value counted when M02,
M30, or another M code specified in a parameter is
executed. This field of the screen provides an
indication only and does not allow a value to be set.
Use a parameter to change an indicated value.
Parts required Specify the number of parts required. When zero is
set, the number of parts is assumed to be infinite. A
value can also be set by a parameter.
Parts count Indicates a cumulative value counted when M02,
M30, or another M code specified in a parameter is
executed. A value can also be set by a parameter.
Power on Indicates a cumulative power-on period. This field of
the screen provides an indication only and does not
allow a value to be set. Use a parameter to change
an indicated value.
Operating time Indicates a cumulative operating period during
automatic operation (excluding the period during
which the operation is stopped or paused). Use a
parameter to change an indicated value.
Cutting time Indicates a cumulative cutting period by linear
interpolation (G01), circular interpolation (G02, G03),
and other cutting feed. Use a parameter to change
an indicated value.
Free purpose This field can be used to indicate the cumulative
period of a specified task such as a coolant-on
period. The meaning of an indicated value varies
from one machine to another. For details, refer to
the operator's manual of the machine tool builder.
Cycle time Indicates the cumulative operating time during a
single cycle of automatic operation (excluding the
period during which the operation is stopped or
paused). When a cycle is started from the reset
state, the indicated value is automatically reset to 0.
The value is also reset to 0 when the power is shut
down.
Current time Date and time set with the CNC.
This data item can also be set by a parameter.
For details of the parameters related to the above, refer to the
parameter manual of each CNC.
NOTE
No negative values may be set in the Parts and
Timer sections.
In the M and S fields of the Timer section, a value
ranging from 0 to 59 can be specified.
